What is Vacuum Forming?
27 Years Experience
75+ Design Awards
1,000+ Manufactured Products
From Idea to Prototype in as Little as Six Weeks!
Ready to Start?
Vacuum Forming is a technique where thermoplastic sheets (like acrylic or polystyrene) are heated and shaped using a mold and vacuum pressure.
Here is a brief overview of Vacuum Forming and why we use vacuum forming during the prototype phase of product development, and for volume production.
How Vacuum Forming Works: The plastic sheet is clamped down, and a mold of the desired shape is placed above it. Heat makes the plastic soft, and the vacuum pulls it onto the mold, giving the product its form.
Budget-Friendly: Vacuum forming is great for prototypes and final products, as it’s way cheaper than other methods like injection molding or CNC machining. No need to break the bank to try out your designs!
Versatile Process for many different types of parts: Whether it’s tiny widgets or large industrial parts, vacuum forming can handle it all. It’s like the chameleon of manufacturing processes!
Eco-Friendly Option: Designers can tweak and test designs quickly, thanks to vacuum forming’s flexibility. Plus, it’s environmentally friendly, with minimal plastic waste since you can recycle leftovers later.
Here are some common questions and answers our clients ask about vacuum forming:
1) What can vacuum forming make?
The heated plastic takes on the shape of the mold underneath, giving endless possibilities of parts to make with a vacuum forming machine.
2) How does vacuum forming work?
A thin plastic sheet is heated until it is formable. The plastic sheet is then stretched over the mold and takes the rough shape of the part. A vacuum is used to suck all the air out between the plastic and the mold; when the plastic cools it has the shape of the part.
3) What is webbing?
Webbing is when the plastic overlaps on itself. It can happen if the plastic sheet sags too much when heating and over stretching.
4) Is the plastic for vacuum forming clear?
The plastic used for vacuum forming can be any colour or clear.
5) Recyclable/Eco friendly?
Thermoplastics are materials that can be recycled and reused.
6) Max thickness of vacuum forming?
Depends on the former, but some sheet thicknesses can go up to 0.45”.
7) Can Acrylic be vacuum formed?
Yes, Acrylic is a thermoplastic material that can be easily shaped using vacuum forming. During the vacuum forming process, acrylic sheets are heated until they become soft and pliable. Then, the softened sheets are placed over a mold, and a vacuum is applied. The atmospheric pressure forces the heated acrylic to conform to the contours of the mold, resulting in the desired shape.
